How to design, construct and install a large stained glass window

Uncategorized November 30, 2015

1.altasThe original visualisation on which the window design was based

1b.Screen Shot 2015-11-30 at 14.37.48

Matching glass colours

3.chot_sheets of glass_BB

The glass is mouth-blown into long cylinders and then formed into sheets through a series of varrying-temperature ovens

4.chu_test - not very good_BB

Making a small test panel with the first cartoon (it did not go well at all!)

5.Screen Shot 2015-11-29 at 17.38.51

After the test panel made quite obvious that the margin of error was very small (1-2mm), I redrew the cartoon using more precise tools for greater accuracy

6.Screen Shot 2015-11-29 at 17.39.29

Early stages of glass cutting

7.Screen Shot 2015-11-29 at 17.44.30

Later stages of glass cutting

8.cutting_finished done

All 650 pieces of glass cut and labelled before being joined together with lead came

8b.Screen Shot 2015-11-30 at 14.36.50

Early stages of leading up – the came is an H-profile which holds the pieces of glass on either side. It is later held together by soldering at each joint

10.leading up2

Later stages of leading up

11.Screen Shot 2015-11-29 at 17.21.07

Once the window has been fully leaded and soldered, a cement-type compound of linseed oil, calcium carbonate, turps and carbon black powder is forced between the gaps in the glass and the lead. This cement helps to strengthen the window. Additional calcium carbonate is spread over the window to dry out the cement – it is later brushed off as part of the final cleaning process.

12.Screen Shot 2015-11-29 at 17.21.35

The angle steel outer frame was bent in the UK, before being shipped to Helsinki for final welding.

13.Screen Shot 2015-11-29 at 17.22.13

The outer frame and ferramenta – a steel internal support structure which was later tied on to the reserve side of the window – prior to installation in the Kunsthalle

14.Screen Shot 2015-11-29 at 17.22.55

The tricky installation process…

15.Screen Shot 2015-11-29 at 17.23.23

The back of the window following installation. The ferramenta – attached with bronze wire ties – is visible from this angle.
